3-piece body ball valve with F x F female threads. Full in-line maintenance without pipeline disconnection. 6000 PSI. Sizes 1/4″ to 2″. Materials: SS/CS/Alloy/Nickel/Brass. SKU: HPBV202
Product Description
Maximize maintenance flexibility and reduce system downtime with the 3 PC Design Ball Valve (SKU: HPBV202) . Engineered with a true three-piece body construction, this valve allows complete in-line maintenance—the center body section can be removed for seal replacement, ball inspection, or cleaning while both end connections remain securely attached to the pipeline. The female x female (F x F) threaded ends enable direct mounting onto male pipe connections without additional adapters. Rated for pressures up to 6000 psi and available in sizes from 1/4″ to 2″, this valve is the preferred choice for critical process lines, chemical injection systems, hydraulic circuits, instrument manifolds, and high-cycle applications where easy servicing and maximum reliability are essential. Available in Stainless Steel, Carbon Steel, Alloy Steel, Nickel Alloy, and Brass, with NPT, BSP, BSPT, or SW end connections.
Product Features
3 PC Body Construction: Three-piece design (left end, center body, right end) allows the center section to be removed while both end connections remain attached to the pipeline.
Full In-Line Maintenance: Perform seal replacement, ball cleaning, seat inspection, or component replacement without disconnecting pipe ends—significantly reducing system downtime.
F x F Female Threads: Direct mount onto male pipe ends, eliminating additional adapter fittings and potential leak points.
High Pressure Capability: Engineered to withstand up to 6000 psi for demanding hydraulic, pneumatic, and process applications.
Wide Material Selection: Available in Stainless Steel, Carbon Steel, Alloy Steel, Nickel Alloy, and Brass—select based on media compatibility, temperature, and corrosion requirements.
Easy Component Access: Bolted construction allows quick disassembly for maintenance, cleaning, or inspection without special tools.
Versatile End Connections: Available in NPT, BSP, BSPT, or SW to suit global piping standards.
Blow-Out Proof Stem: Captured stem design prevents accidental ejection under system pressure.
Bidirectional Flow: Can be installed in either direction without performance loss.
Quarter-Turn Operation: Simple 90° rotation for fast, positive shut-off with tactile feedback.
Multiple Seat & Seal Options: Available with PTFE, PEEK, Delrin, or other seat materials for extended temperature and chemical compatibility (upon request).
Interchangeable Components: Internal parts are standardized for easy replacement and reduced spare parts inventory across multiple valves
Key Bullet Points (At a Glance)
Design: 3 PC (Three-Piece Body Construction)
Configuration: Female x Female (F x F) threaded ends
Pressure Rating: Up to 6000 psi
Size Range: 1/4″ to 2 inches
End Connections: NPT / BSP / BSPT / SW
Material Options: Stainless Steel / Carbon Steel / Alloy Steel / Nickel Alloy / Brass
SKU: HPBV202
